Specification
|
Standards and Protocols |
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p |
|
Interface |
16 10/100/1000Mbps RJ45 Ports |
|
Network Media |
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) |
|
Fan Quantity |
Fanless |
|
Power Supply |
External Power Adapter(Output: 9VDC/0.6A) |
|
Power Consumption |
Maximum: 9.27W (220V/50Hz) |
|
Dimensions ( W x D x H ) |
11.3*4.4*1.0 in. (286*111.7*25.4 mm) |
|
Switching Capacity |
32Gbps |
|
Packet Forwarding Rate |
23.81Mpps |
|
MAC Address Table |
8K |
|
Packet Buffer Memory |
4.1Mb |
|
Jumbo Frame |
9KB |
|
Quality of Service |
Support Port-based/802.1p/DSCP priority |
|
L2 Features |
IGMP Snooping V1/V2/V3 |
|
VLAN |
Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs) |
|
Transmission Method |
Store-And-Forward |
