TP-Link VIGI NVR1004H-4P-2TB 4 Channel PoE+ Network Video Recorder
Hurry up! Sales Ends In
Hurry! Only 3 Left in Stock!
-
- 4-Channel Live View and 4K HDMI Video Output
- 4× 10/100 Mbps PoE+ Ports with 53 W PoE Budget△
- Up to 8-ch @ 2MP (25fps) / 4-ch @ 4MP (25fps) Decoding Capability
- 4-Channel Synchronous Playback†
- 80 Mbps Incoming Bandwidth and 60 Mbps Outgoing Bandwidth
- 1× SATA Interface and 1 Up to 10 TB (1× 2TB HDD Preinstalled)
- H.265+ Compression Technology
- HDMI and VGA Simultaneous Output
- Remote Monitoring
Video and Audio IP Video Input 4-Channel Incoming Bandwidth 80 Mbps Outgoing Bandwidth 60 Mbps HDMI Output Resolution 1 Channel, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz VGA Output Resolution 1 Channel, Resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz Video Output Mode HDMI/VGA Simultaneous Output Multi-View Display 1/4 DECODING Audio Compression G.711A/G.711U/G.726 Video Compression H.265+/H.265/ H.264+/H.264 Record Resolution 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/
2CIF/CIF/QCIFSynchronous Playback 4-Channel† Capability • 25fps:
2-ch @ 8MP, 4-ch @ 4MP
• 30fps:
4-ch @ 4MP, 3-ch @ 5MPRecord Management Record Mode • Manual Recording
• Scheduling Recording
• Motion Detection RecordingPlayback Mode • Instant Playback
• Regular Playback
• Tag Playback
• Event PlaybackBackup Mode • Regular Backup
• Video Clip BackupPlayback Function • Play
• Pause
• Stop
• Fast Forward
• Fast Backward
• Play By Frame
• Full Screen
• Video Clip
• Export Clip
• Digital Zoom
• Lock Recording
• Audio On/OffNETWORK Protocol UPnP (Plug and Play), NTP (Network Timing), SMTP, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP Mobile Phone Access Android, iOS Web Browser Chrome (57+), Firefox (52+), Edge (91+) Interoperability ONVIF Profile S/T/G, CGI External Interface Network Interface 1, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface USB Interface 1 Front USB 2.0 Port, 1 Rear USB 2.0 Port Audio Interface 1-ch RCA Input; 1-ch RCA Output Alarm In/Out N/A Serial Interface N/A Power 1× DC Jack Reset Button 1 Speaker N/A eSATA N/A HDMI 1 VGA 1 HARD DISK SATA 1 SATA Interface Capacity • Up to 10 TB Capacity for Each HDD
• 1 × 2TB HDD PreinstalledPoE Standard 802.3at/af Compliant Interface 1- 4, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface PoE Budget 53 W△ Available for All PoE+ Ports, 30 W Max per Port Alarm General Alarm • Motion Detection
• Video Tampering
• Scene Change Detection
• Line-Crossing Detection
• Intrusion Detection
• Region Entering Detection
• Region Exiting Detection
• Loitering Detection
• Object Abandoned/Removal Detection
• Vehicle Detection
• Human Detection
• Abnormal Sound Detection
• Smart Frame
Note: The alarm function requires the use of a camera.Anomaly Alarm • Video Loss
• Offline and IP Conflict
• Disk Exception
• Login Exception
Note: The alarm function requires the use of a camera.Alarm Linkage • Recording
• White Light Alarm
• Buzzer
• Log
• Audible Alarm
Note: The alarm function requires the use of a camera.GENERAL Storage Temperature -40–70 °C Storage Humidity 10%~90% RH Non-Condensing Package Contents • VIGI Network Video Recorder
• Power Adapter
• Power Cables
• Rubber Feet
• Mouse
• Quick Installation GuideWorking Temperature • NVR: -10–55 °C
• Power Adapter: 0–40 °CWorking Humidity 10%~90% RH Non-Condensing Dimensions( W X D X H ) 246.2 × 148.2 × 45 mm Power Supply 53.5V DC/1.31A Power Consumption • 4.25 W (Without Disk)
• 13.10 W (With Disk)Certifications CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI
