Features
- 802.11ac Wave2 Wi-Fi – 1300 Mbps on the 5 GHz band and 600 Mbps on the 2.4 GHz band.
- 3×3 MIMO Technology – Transmitting and receiving data on three streams to pair flawlessly with your 3×3 clients.
- Boosted Wi-Fi Coverage – Beamforming technology delivers a highly efficient wireless connection.
- MU-MIMO – To help your devices achieve optimal performance by making communication more efficient.
- Personalized Management – Advanced features like Parental Controls, Guest Network, and Access Control provide individualized tools for network management.
- Intelligent Connection – Smart Connect directs clients to the less congested band and Airtime Fairness optimizes the time usage.
Specification
|
HARDWARE FEATURES |
|
|
Interface |
4 10/100/1000Mbps LAN Ports |
|
1 10/100/1000Mbps WAN Port |
|
|
Button |
Reset Button |
|
WPS/Wi-Fi Button |
|
|
Power On/off Button |
|
|
External Power Supply |
US version 12V/1.5A |
|
EU version 12V/1A |
|
|
Dimensions ( W x D x H ) |
8.5 × 4.6 × 1.26 in (215 × 117 × 32 mm) |
|
Antenna |
4 Fixed Omni Directional Antennas |
|
WIRELESS FEATURES |
|
|
Wireless Standards |
IEEE 802.11a/n/ac 5 GHz |
|
IEEE 802.11b/g/n 2.4 GHz |
|
|
Frequency |
2.4 GHz and 5 GHz |
|
Signal Rate |
1300 Mbps on 5 GHz + 600 Mbps on 2.4 GHz |
|
Reception Sensitivity |
5 GHz: |
|
11a 6Mbps:-98dBm, 11a 54Mbps:-78dBm |
|
|
11ac VHT20_MCS0:-98dBm, 11ac VHT20_MCS8:-72dBm |
|
|
11ac VHT40_MCS0:-92dBm, 11ac VHT40_MCS9:-68dBm |
|
|
11ac VHT80_MCS0:-89dBm, 11ac VHT80_MCS9:-64dBm |
|
|
2.4 GHz: |
|
|
11g 6Mbps:-97dBm, 11a 54Mbps:-77dBm |
|
|
11n VHT20_MCS0:-97dBm, 11n VHT20_MCS8:-72dBm |
|
|
11n VHT40_MCS0:-92dBm, 11n VHT40_MCS9:-67dBm |
|
|
Transmit Power |
CE: <20dBm(2.4 GHz), <23dBm(5.15 GHz~5.25 GHz) |
|
FCC:<30dBm(2.4 GHz & 5 GHz) |
|
|
Wireless Functions |
Enable/Disable Wireless Radio, WMM |
|
Wireless Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions |
|
Guest Network |
2.4 GHz Guest Network, 5 GHz Guest Network |
|
SOFTWARE FEATURES |
|
|
Quality of Service |
Device Prioritization |
|
WAN Type |
Dynamic IP/Static IP/PPPoE(Dual Access)/PPTP(Dual Access)/L2TP(Dual Access) |
|
Management |
Parental Controls, Local Management, Remote Management |
|
DHCP |
Server, DHCP Client List, Address Reservation |
|
Port Forwarding |
Port Forwarding, Port Triggering, UPnP, DMZ |
|
Dynamic DNS |
DynDns, NO-IP, TP-Link |
|
Access Control |
Local Management Control, White List, Black List |
|
Firewall Security |
SPI Firewall, IP and MAC Address Binding |
|
Protocols |
Supports IPv4 and IPv6 |
|
Advanced Features |
MU-MIMO |
|
Beamforming |
|
|
Smart Connect |
|
|
Airtime Fairness |
|
|
Quality of Service |
|
|
OTHERS |
|
|
Certification |
CE, FCC, RoHS |
|
Package Contents |
Wireless Router Archer C80 |
|
Power Adapter |
|
|
RJ45 Ethernet Cable |
|
|
Quick Installation Guide |
|
|
System Requirements |
Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, |
|
NetWare, UNIX or Linux |
|
|
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other |
|
|
Java-enabled browser |
|
|
Cable or DSL Modem |
|
|
Subscription with an internet service provider (for internet access) |
|
|
Environment |
Operating Temperature: 0℃~40℃ (32℉ ~104℉) |
|
Storage Temperature: -40℃~70℃ (-40℉ ~158℉) |
|
|
Operating Humidity: 10%~90% non-condensing |
|
|
Storage Humidity: 5%~90% non-condensing |
|
