TP-Link HX510-PoE AX3000 Whole Home Mesh WiFi 6 AP with PoE
Hurry up! Sales Ends In
Hurry! Only 3 Left in Stock!
| HARDWARE FEATURES | |
|---|---|
| Interface | 1× 2.5 Gbps WAN/LAN Port 1× Gigabit LAN Port (both support 802.3at PoE) *Per Unit |
| Button | Reset Button |
| External Power Supply | IEEE 802.3at PoE or 12V DC |
| Dimensions ( W x D x H ) | 6.1 × 6.1 × 2.7 in (154× 154 × 68.6 mm) |
| WIRELESS FEATURES | |
|---|---|
| Wireless Standards |
Wi-Fi 6 IEEE 802.11a/n/ac/ax 5 GHz IEEE 802.11b/g/n/ax 2.4 GHz |
| Frequency | 2.4 GHz and 5 GHz |
| Signal Rate |
AX3000 5 GHz: Up to 2402 Mbps (HE160) 2.4 GHz: Up to 574 Mbps (HE40) |
| Transmit Power | FCC: <30 dBm (2.4 GHz) <30 dBm (5 GHz) CE: <20 dBm (2.4 GHz) <23 dBm (5 GHz) |
| Wireless Security | WPA/WPA2/WPA3-Personal |
| Multi-SSID | 2× 5 GHz Multi-SSID 2× 2.4 GHz Multi-SSID |
| Mesh Technology | EasyMesh compatible, and support 802.11k/v/r |
| SOFTWARE FEATURES | |
|---|---|
| Quality of Service | WMM |
| Advanced Features | Parental Controls, QoS (Quality of Service), Address Reservation, Port Forwarding, WiFi Schedule, Wireless Statistics, Guest Network, Beamforming, MU-MIMO, Band Steering, Airtime Fairness |
| WAN Type | Dynamic IP/Static IP/PPPoE |
| Management | Local management: WebGUI, Aginet app (for end users) Remote management: TR-069, TR-098, TR-181, TR-369, TR-111,TR-143 for service providers Aginet App for end users (need to log in wtih TP-Link ID and bind your device to it) Cloud management: TP-Link Aginet Unified Cloud (TAUC) |
| VPN | PPTP, OpenVPN, IPSec |
| Firewall Security | DoS, SPI Firewall, IP and MAC Address Binding |
| Protocols | IPv4 IPv6 |
| Working Modes | Router Mode Access Point Mode |
| OTHERS | |
|---|---|
| Package Contents |
HX510-PoE (1-Pack) 1× HX510-PoE Unit 1× RJ45 Ethernet Cable 1× Power Adapter Ceiling/wall-mounting Kit Quick Installation Guide |
| Certifications | CE, FCC |
| Environment | Operating Temperature: 0℃–40℃ (32℉–104℉) Storage Temperature: -40℃–60℃ (-40℉–140℉) Operating Humidity: 10%–90% non-condensing Storage Humidity: 5%–90% non-condensing |
